Day 4: What does "400 Wh" actually mean?
Wh measures energy capacity, not speed — and the same 400 Wh battery can take you 45 km or 130 km depending on four variables: assist level, terrain, rider weight, and temperature. Learn how these factors interact, see them in action on the Giant Explore E+ 2 GTS, and use a simple formula to sanity-check any range claim.
Your eBike's battery is almost always advertised with a number like "400 Wh" or "500 Wh." It looks like a simple power rating. It's actually a promise — and how far that promise takes you depends on four factors that have nothing to do with the battery itself.
Today's concept: watt-hours measure energy, not speed
Wh stands for watt-hours: the amount of energy the battery can deliver at a sustained rate. A 400 Wh battery can theoretically supply 400 watts for one hour, 200 watts for two hours, or 100 watts for four hours. Whatever combination you draw, the total energy available stays the same.
That's the key idea. Your motor doesn't care what the battery is — it only cares how much energy is being delivered, and for how long. Once you see it that way, the wide range estimates you see on manufacturer spec sheets (like "45–130 km") stop feeling like marketing noise and start making sense.
A quick reference for context: most commuter eBikes ship with 400–500 Wh batteries, which translates to roughly 40–80 km of real-world range depending on conditions 1. Premium touring models can reach 625–750 Wh. Entry-level models sometimes ship with 300 Wh — fine for short daily commutes, but limiting in hilly terrain.
Why it matters: four factors that eat into your Wh budget
The advertised range on any eBike is a best-case figure — flat road, moderate temperature, light rider, lowest assist mode. Real riding rarely matches that. Here are the four variables that shift the needle most:
1. Assist level — This is the biggest single lever. From Day 3, you already know that switching from Eco (~25 W) to Turbo (~300 W) can shrink range by 4–5×. On a 400 Wh battery, that's the difference between 80 km and 20 km on the same charge.
2. Terrain — Climbing hills requires the motor to sustain high wattage output for extended periods. A route with 200 m of total elevation gain can consume 20–30% more energy than a flat route of the same distance. Most eBikes don't recover meaningful energy on descents — there's no regenerative braking in most pedal-assist systems.
3. Rider and cargo weight — Every extra kilogram means more work for the motor, especially uphill. A rough rule of thumb: each additional 10 kg costs approximately 5–8% of range on mixed terrain. A 90 kg rider with a loaded rear pannier will see noticeably shorter range than a 65 kg rider on the same route at the same assist level.
4. Temperature — Lithium-ion cells lose capacity in cold weather. At 0°C, a 400 Wh battery may behave more like a 320–340 Wh battery 3. Below –10°C, some manufacturers recommend prewarming the battery indoors before riding. Summer heat above 35°C accelerates long-term cell degradation, though the effect on a single ride is less acute than cold.
One real example: Giant Explore E+ 2 GTS
The Giant Explore E+ 2 GTS is a commuter and fitness eBike available in many markets for roughly $2,700–$3,200 depending on region and spec. It runs a Yamaha SyncDrive Sport motor paired with a 400 Wh integrated downtube battery 1.
Giant's official range estimate for the Explore E+ 2 GTS is 45–130 km — a spread that looks absurd at first glance. Apply the four factors and it becomes accurate:
- 45 km: heavier rider, steep hills, Turbo mode, cold morning
- 130 km: lighter rider, flat path, Eco mode, mild temperature
The Yamaha SyncDrive Sport draws around 250–300 W in its highest setting and as little as 40–60 W in Eco — almost identical to the wattage structure you saw in Day 3's Bosch-equipped Cannondale. The battery on the Explore E+ 2 GTS is removable: you slide it out of the downtube frame slot and charge it indoors, which matters for the temperature point — keeping the battery at room temperature during storage protects cell health over time.
One small exercise
Before your next ride (or the next time you're researching a bike), try this three-step check:
- Find the battery's Wh number — usually on the product page, frame label, or the battery itself.
- Estimate your typical route: hilly or flat? What assist level will you use most?
- Run this rough sanity check on any advertised range figure:
Estimated range (km) ≈ Wh ÷ average watts × speed
Example for a 400 Wh battery at Tour mode (~60 W average) riding at 20 km/h:
400 ÷ 60 × 20 = ~133 km (flat, ideal conditions)
Subtract roughly 25% for hills, another 10–15% for heavier weight, and another 10–15% for cold weather — and you'll land close to what you'd actually see on a real mixed-terrain ride. The formula isn't precise, but it makes the manufacturer's stated range feel honest rather than arbitrary.
Coming up in Day 5: eBike displays and app connectivity — how to read the live data your bike is already generating, and what the numbers on your screen actually tell you mid-ride.
